How to set up prefix and suffix for TEEMI 2D scanners

To configure a prefix or suffix, you can generate the programming barcode yourself. The barcode format should be Code 128 or Data Matrix.

Examples:

1. Adding three "Enter" keystrokes as a prefix:
   • The programming code is: ^3080400990d0d0d.
     • ^3: Enters programming mode.
     • 080400: Code to add a prefix.
     • 99: Applies the setting to all barcode types.(check Symbology Charts here)
     • 0d: Represents one "Enter" keystroke. Repeating this three times (0d0d0d) adds three "Enter" keystrokes.(check ASCII Conversion Chart here)
     • .: Saves the configuration.
2. Adding three "Enter" keystrokes as a suffix:
   • The programming code is: ^3080500990d0d0d.
     • ^3: Enters programming mode.
     • 080500: Code to add a suffix.
     • 99: Applies the setting to all barcode types.
     • 0d: Represents one "Enter" keystroke. Repeating this three times (0d0d0d) adds three "Enter" keystrokes.
     • .: Saves the configuration.

Steps to create the configuration code:

1. Download and install the barcode creator software here.
2. Click the barcode symbol, then click on a blank space to start creating the configuration code.

3. Double-click the barcode. A small window will appear, allowing you to modify the data and symbology.

4. Set the symbology to Data Matrix in the barcode settings.

5. Copy the command string and paste it into the "Screen Data" field under the data source settings.
